| Article number: | 281405-012 |
| Quantity: | 1 |
All New Light alloy frame with off-road riding in mind.
- Hydraulic Lock out suspension and discs for smooth control in all terrain
- 2 X 9 Shimano drivetrain and cranks will last and perform for ages
SPECIFICATIONS
FRAME 6061 Light alloy with 3D dropouts, integrated headtube and internally routed cables
FORK SR XCM 100mm travel with 30mm stanchions & Hydraulic Lockout, XS/S/M = 27.5, ML/L/XL = 29er
WHEELSET/RIMS Weinmann U28 disc double wall alloy 32H
HUBS Fr: Shimano TX505 QR Centrelock Disc, Rr: Shimano TX505 QR Cassette Centrelock Disc
SPOKES Stainless black
TYRES Kenda Booster wire bead, XS-M=27.5 x 2.2", ML-XL=29 x 2.2" AV tubes
SHIFTERS Shimano Altus EF505 18 speed
FRONT DERAILLEUR Shimano Altus 2 X
REAR DERAILLEUR Shimano Altus 9sp Shadow
CRANKSET Shimano MT100 alloy, 22/30/40T: XS/S = 170mm,M-XL=175mm
BOTTOM BRACKET Shimano UN-100 cartridge
CHAIN KMC Z9 9sp
CASSETTE Shimano Cassette HG-20 11-34T 9sp
BRAKES Shimano MT200 hydraulic disc, 160mm centrelock rotor
BRAKE LEVERS Shimano EF505 hydraulic disc, 160mm centrelock rotor
HANDLEBAR Alloy oversize low rise, 9 degree sweep, XS/S=640mm, M/ML=660mm, L/XL=680mm
HANDLEBAR STEM 3D Forged oversize alloy Ahead 6 deg rise XS=60mm,S=60mm,M/ML=75mm, L/XL=90mm
HEADSET VP 1 1/8th Ahead integrated
GRIPS Kraton
PEDALS VP Platform with ball bearings
SADDLE Men's Sport
SEAT POSTS Alloy 27.2, alloy QR: XS/S=300mm, M/ML=350mm, L/XL=400
