| Article number: |
287865-009 |
The Hammer LT range of 160/145mm trail bikes, are engineered in Germany to be light, but tough enough to handle steeper and more aggressive terrain than our Hammer S line. Small frame size bikes features 27.5 wheels for lower standover and all bikes in the range feature Rockshox front and rear suspension, long-travel Syncros dropper posts, Shimano hydro brakes and SRAM's excellent Eagle 12 speed drive trains. Added to that, LT's feature our 'Stashbox' in the frame which is fully equipped with all the quality Syncros mini tools you need out on the trail
FEATURES:
- German-engineered tough alloy 145mm travel frame with 'Stash Box' fully equipped with Syncros trail tools
- Tough Rockshox air sprung suspension front and rear
- SRAM SX Eagle 12 speed components for bullet proof shifting
- Shimano MT420/401 hydraulic 4 piston brakes
- Full Syncros cockpit with internally routed dropper post
| Frame |
AL-6061 Ultralight Butted tubing, 145mm travel, cartridge bearing pivots, 1.5" tapered headtube, PF92 BB, 12 x 148m, stash box with tools |
 |
| Fork |
Rockshox 35 Silver TK Solo Air, 160mm, air spring, 1.5" taper, fixed rebound, lock-out, Boost 110 15mm axle - S=27.5, M/L/XL=29er |
|
| Rear Shock |
Rockshox Delux Select + Debonair, rebound adjust |
|
| Rear Derailleur |
SRAM SX Eagle |
|
| Shifters |
SRAM SX Eagle, 12 speed |
|
| Crankset |
SRAM X1 1000 Eagle,DUB, 32T |
|
| Brakes |
Shimano MT420 hydraulic, 203 front/180mm rear rotors |
|
| Brake Levers |
Shimano MT401hydraulic |
|
| Wheelset / Rims |
Alex EXR 30 Double-wall Alloy with eyelet 32H, Tubeless Ready |
|
| Hubs |
Front: Alloy, 110x15mm 32H, Rear: Alloy 148x12mm, 32H |
|
| Spokes |
Stainless steel |
|
| Cassette |
SRAM PG-1210 Cassette, 11-50T, 12 speed |
|
| Handlebar |
Syncros Hixon 2.0 31.8mm, with 12mm rise, 9 deg sweep |
|
| Handlebar Stem |
Syncros FL 2.0 31.8, 6 deg rise |
|
| Headset |
Integrated Threadless 1 1/8th - 1.5" (with extra lower geometry adjust cup for 27.5+ ) |
|
| Grips |
Syncros Lock-on |
|
| Tyres |
Fr: Maxxis Minion DHF 3CMaxxTerra/EXO 2.5"; Rr Maxxis Aggressor, 3CMaxxTerra/EXO 2.3" (2.5" on S size). Foldable, Tubeless Ready |
|
| Saddle |
Syncros ER2.5 |
